Type of Bellows
- Circular Bellow( Standard Range )
- Square Bellow ( On Special Request )
- Rectangular Bellow( On Special Request )
Type of Expansion Joints
- Single Expansion Joints
- Single Tied Expansion Joints
- Hinged Expansion Joints
- In – Line Pressure Balanced Expansion Joints
- Gimbal Expansion Joints
- Universal Expansion Joints
- Pressure Balanced Expansion Joints
Type of End Fittings
- Fixed Flange
- Welded End
- Vanstone Flange / Floating Flange
Note
Assemblies areTIG welded and tested according to customer request. Assemblies are normally supplied with new end terminations, however customer supplied ends can be used if practicable. Fully compressed units to be cold. Extended on Installation.
Inner sleeves are an additional component to be specified at time of order.
Technical Specifications – SS ‘ R-10 ‘ Series
| NB | PN | WP (Bar) | No of Corrugations | Cuff ODB (mm) | Bellow ODA ( mm) | Axial +/mm | Cuff (mm) | L (mm) |
|---|---|---|---|---|---|---|---|---|
| 50 | R50-10 | 10 | 7 | 59.3 | 81.3 | 15 | 11 | 107.5 |
| 65 | R65-10 | 10 | 9 | 75.2 | 99.8 | 20 | 12.3 | 134.6 |
| 80 | R80-10 | 10 | 7 | 87.5 | 114 | 15 | 13.3 | 120 |
| 100 | R100-10 | 10 | 9 | 112 | 142 | 20 | 15.1 | 150 |
| 125 | R125-10 | 10 | 9 | 137 | 170.5 | 20 | 16.7 | 163 |
| 150 | R150-10 | 10 | 10 | 165 | 201 | 25 | 18.7 | 196 |
| 200 | R200-10 | 10 | 10 | 219 | 259 | 25 | 10-15 | 240 |
| 250 | R250-10 | 10 | 10 | 274 | 314 | 25 | 10-15 | 240 |
| 300 | R300-10 | 10 | 11 | 324 | 364 | 25 | 10-15 | 262 |
| 350 | R350-10 | 10 | 8 | 355.6 | 396 | 20 | 10-15 | 196 |
| 400 | R400-10 | 10 | 8 | 415 | 452 | 20 | 10-15 | 250 |
| 450 | R450-10 | 10 | 8 | 465 | 510 | 20 | 10-15 | 245 |
| 500 | R500-10 | 10 | 8 | 515 | 570 | 20 | 10-15 | 260 |
| 600 | R600-10 | 10 | 8 | 355.6 | 670 | 20 | 10-15 | 290 |
